- Jet Tools
- Cast Iron Head
- Large quill allows greater accuracy
- Head casting features a permanently lubricated ball bearing spindle assembly using four heavy duty ball bearings mounted in an enclosed quill for extended life
- Table tilts 45
- Massive T-slotted production table
- Large ground steel column diameter for maximum head and table support
- 4-3/4 stroke for deep hole applications
- Accurate depth stop for precise hole depths
- Includes 5/8″ chuck and arbor
- Specifications
- Stock Number: 354402
- Model Number: J-2550
- Drilling Capacity Cast Iron: 3/4″
- Drilling Capacity Mild Steel: 5/8″
- Column Diameter: 3-5/8″
- Distance Column to Spindle: 10-1/2″
- Range of Spindle Speeds: 150-4200 RPM
- Spindle Travel: 4-3/4″
- Spindle Distance to Base: 43-1/2″
- Spindle Distance to Table: 24″
- Table Size: 18-1/2 x 16-1/2″
- Table Travel: 21-1/2″
- T-Slots Number and Size: 3 x 1/2″
- T-Slot Centers: 4″
- Work Table Weight Capacity: 66 lbs.
- Spindle Taper: MT-3
- Base Dimensions: 22-3/4 x 17-3/4″
- Base Work Table: 13 x 14-1/2″
- Motor: 1 HP; 1 Ph; 115/230V; Prewired 115V
- Overall Dimensions: 33-1/2 x 18-1/2 x 67″
- Net Weight: 304 lbs.
“
