JET Tools Jet HBS-812G; 8 X 12″ Horizontal/Vertical Geared Head Bandsaw 413460

Jet

HBS-812G; 8 x 12″ Horizontal/Vertical Geared Head Bandsaw 413460

Innovative and built to last; that’s how customers describe the latest addition to the JET line of saws. Easy speed change; quick lock vise and large 8″ wheels enhance the convenience of this rugged machine. It is everything you expect from a JET saw.

FEATURES:

• Heavy-duty geared head transmission for quick speed changes.
• Heavy-duty cast iron saw bow and head.
• Hardened and ground worm gear.
• Large 8″ wheels and handle for easy movement.
• Quick-positioning vise swivels to 45°; reducing set up time.
• Built-in; self propelled blade brush extends blade life.
• Vertical work table.
• Coolant system.
• Adjustable material stop.
• 3/4″ Bi-Metal blade.

SPECIFICATIONS:

Cutting Capacity (W x D) (In.)	8 x 12
Round at 90 Degrees (In.)	8
Round at 45 Degrees (In.)	5
Rectangle at 90 Degrees (In.)	8 x 11-1/4
Rectangle at 45 Degrees (In.)	5 x 8
Vise Swivels (Deg.)	45°
Blade Speeds (SFPM)	145; 200; 245
Blade Wheel Diameter (In.)	11-1/2
Blade Length (In.)	93
Blade Size (In.)	3/4 x .035 x 93
Bed Height (In.)	43
Motor (HP)	1 HP; 115/230V; 1Ph
Overall Dimensions (L x W x H) (In.)	51 x 19 x 43
Drive	Geared Head

“
