Enerpac
XC-Series Cordless Hydraulic Pump 4/3 Valve 120 in3 Usable Oil 2 Battery Kit w/ 115V Charger XC1402MB
The XC-Series cordless pump is ideal for jobs that require a combination of portability; speed; and safety. These cordless pumps are perfect for remote locations without access to power; but also indoors where trip hazards; ergonomics or size is a concern. The XC-Series cordless pump is compatible with all Enerpac hydraulic tools and small to medium sized cylinders.
FEATURES:
- Lightweight design with integrated handle and carrying strap for portability.
- Bladder reservoir prevents contamination and allows pump usage in any position.
- Powerful 1/2 horsepower motor and 28 volt Lithium-Ion battery deliver exceptional speed and run time.
- High-strength fiberglass reinforced composite shroud for superior durability in demanding job site environments.
- Cordless technology eliminates tripping hazards found in other electric or air powered pumps.
- The Lithium-Ion battery provides superior run time; even under extreme job site conditions.*
-279 cuts of 3/8 inch reinforcing bar using the WHC750 Cutter
-112 lifts with the WR5 Spreader
-44 splits on 1-inch; grade 8 nuts using the NC3241 Nut Splitter
-28 lifts of an RC104 - *Actual number of cycles per charge will vary depending on condition of tool; battery and ambient conditions. Battery life with double-acting tools is approximately 75% of that for comparable; single-acting tools.
- The XC-Series cordless pump is CSA and CE compliant.
SPECIFICATIONS:
| Maximum Operating Pressure (psi) | 10;000 |
|---|---|
| Cylinder Compatability | Double-acting |
| Reservoir Capacity (in3) | 120 |
| Usable Oil Capacity (in3) | 120 |
| Maximum Flow at Rated Pressure | 15 in3/min |
| Output Flow Rate (in3/min) No Load | 125 |
| Output Flow Rate Load (in3/min) | 15 |
| Output Flow Rate (in3/min) 2000 psi | 30 |
| Number of Outlets | 2 |
| Motor Size (hp) | 0.5 |
| Duty Cycle | Intermittent |
| Valve Function | Advance / Hold / Retract |
| Valve Operation | Manual |
| Valve Type | 4-way; 3-position |
| Power Source | Battery |
| Charger Voltage (VAC) | 115 |
